l Advantages:

1. design, production, transportation, after-sales protection one-stop service.

2. We have our own frame factory

3. Professional packing and transportation team

4. A dedicated greenhouse team services for you

l Characteristics:

1. Simple structure and easy to install

2. Use accessories connect without welding

3. Hot dip galvanized steel frame, corrosion resistance, service life of about 15 years

4. Covering materials include PO film, PEP film, HDPE woven plastic film, anti-insect net, shade cloth, etc.

5. Effectively prevent natural disasters and increase output

l Specification:

Commodity : Tianyingtai(TYT) Brand Single-span Greenhouse

1. Length: 10m-100m (can be customized according to requirements)

2. Width: 6m-17m (can be customized according to requirements)

3. frame structure:

(1)pre-galvanized steel frame/hot-galvanized steel frame

(2) frame tube: round tube, oval tube

(3) Size; 32-60mm,30*50mm~40*80mm

(4) Zinc coating: 40-210g

(5) Thickness: 1-2.5mm

4.Covering

 (1) PO/PEP/HDPE woven plastic film    Thickness: 100μm-200μm

(2) Polycarbonate             Thickness:  double/three layers

5. Parameters:

 (1) wind load: 0.5KN/㎡

(2) Snow load: 0.35KN/㎡

(3) Maximum rainfall: 140mm/h

(4) hanging weight: 15kg/㎡

6. Optional system: cooling system, shading system, thermal insulation system, heating system, hydroponic system, intelligent control system

l Usage Scenarios:

 Vegetable planting, flower planting, animal breeding
