l Advantages:

1. design, production, transportation, after-sales protection one-stop service.

2. We have our own frame factory

3. Professional packing and transportation team

4. A dedicated greenhouse team services for you

l Characteristics:

1. Use accessories connect without welding

2. High quality hot dip galvanized steel frame, corrosion resistance, service life more than 15 years

3. Covering materials include PO / PEP/ HDPE woven plastic film, Polycarbonate, and Tempered Glasses etc.

4. It can be matched with a variety of intelligent systems to achieve intelligent control

5. Provide a comfortable environment for plant growth and increase production

l Specification:

Commodity : Tianyingtai(TYT) Brand Multi-Span Greenhouse

Type: Film multi-span greenhouse, polycarbonate multi-span greenhouse,Glass greenhouse

Frame structure:

(1)Hot dip galvanized steel Frame

(2) Main post: 150*150mm-100*100mm

(3) Auxiliary post : 120*60mm-100*50mm

(4) Thickness: 1-2.5mm

(5) Truss: 50*50*2.5mm

(6) Zinc coating: average 210g/㎡

(7) Gutter: thickness 2.0-2.75mm, zinc coating 275g/㎡

Covering

(1) PO/PEP/HDPE plastic film     single layer film covering / double layers films

one layer thickness: 120μm-200μm

(2) Polycarbonate: double/three layers

(3) tempered glass

single layer: 4mm/5mm

double layer 5+6+5 mm

can be customized according to customer requirements

Film multi-span greenhouse Parameters:

(1) Wind load: 0.55KN/㎡

(2) Snow load: 0.45KN/㎡

(3) Maximum rainfall: 140mm/h

(4) Planting bearing: 0.2KN /㎡

Optional system: internal/external shading system, cooling system, heating system, irrigation system, planting system, hydroponic system, supplementary light system, intelligent control system

l Usage Scenarios: Vegetable planting, flower planting, animal breeding
